Whole barrel oil well pump
The whole barrel oil pump developed by our company is designed and manufactured according to API Spec 11AX-2015, GB/T18607-2017, SY /T5059-2009 and other standards
Product introduction:
The whole barrel oil pump developed by our company is designed and manufactured according to API Spec 11AX-2015, GB/T18607-2017, SY /T5059-2009 and other standards. It adopts domestic advanced technology and has reasonable design, high oil pumping efficiency and corrosion resistance. , Wear resistance and other advantages.
The main components of the pump: The inner hole of the pump barrel is treated with chromium plating or nickel-phosphorus composite plating, the plunger is treated with medium carbon steel surface spray-welded nickel-based alloy, the valve ball and valve seat are made of 9Cr18Mo, 6Cr18Mo or hard alloy, which has corrosion resistance, high hardness, Features such as long service life.
The main technical parameters
| Specification | Nominal Diameter（mm） | Stroke （m） | Plunger Length（m） | Connect the outer diameter of the tubing（mm） | Pump Constant（m3/d） | Connecting oil rod diameter（mm） |
| 25-125TH | 31.75 | 0.6~9.0 | 1.2 | 73 | 1.14 | 19 |
| 25-150TH | 38.10 | 0.6~9.0 | 1.2 | 73 | 1.642 | 19 |
| 25-175TH | 44.45 | 0.6~9.0 | 1.2 | 73 | 2.235 | 19 |
| 25-225TH | 57.15 | 0.6~9.0 | 1.2 | 73 | 3.691 | 19 |
| 30-250TH | 63.50 | 0.6~9.0 | 1.2 | 88.9 | 4.560 | 22 |
| 30-275TH | 69.85 | 0.6~9.0 | 1.2 | 88.9 | 5.518 | 22 |
| 35-325TH | 82.60 | 0.6~9.0 | 1.2 | 101.6 | 7.707 | 22 |
| 35-375TH | 95.30 | 0.6~9.0 | 1.2 | 114.3 | 10.261 | 25 |
